型号：LSQ-HX横销式气动快速接头
产品详情
描述：
LSQ-HX横销式气动快速接头（碳钢、黄铜）
→产品描述：单手操作，使用介质用颜色区分，彩镀用于空气和水，红色用于乙炔，绿色用于氧气，蓝色用于二氧化碳，德国广泛应用。
→技术优势：单手操作，钢销锁紧设计。
→产品应用：造船行业，船务维修行业以及各种需避免介质混乱误插队工业系统。
→工作压力：1.0Mpa
→工作温度：-20℃+120℃
| PARTNO. | LS | ￠D | HEX1 | A | T | d |
| LSQ-HX-04SF | 64.8 | 36 | 32 | 14 | G1/2 | ￠12 |
| LSQ-HX-06SF | 66 | 36 | 32 | 16 | G3/4 | ￠12 |
| PARTNO. | LS | ￠D | HEX1 | A | T | d |
| LSQ-HX-04SM | 66 | 36 | 32 | 14 | ZG1/2 | ￠12 |
| LSQ-HX-06SM | 67.8 | 36 | 32 | 16 | ZG3/4 | ￠12 |
| PARTNO. | LS | ￠D | HEX1 | A | ￠T | d |
| LSQ-HX-04SH | 89.5 | 36 | 34 | 38 | 16 | ￠12 |
| LSQ-HX-06SH | 89.5 | 36 | 34 | 38 | 21 | ￠12 |
| PARTNO. | LP | A | C | CP | ￠T | d |
| LSQ-HX-03PH | 74 | 26 | 37 | 19.5 | 14 | ￠10 |
| LSQ-HX-04PH | 73 | 26 | 36 | 19.5 | 16 | ￠10 |
| LSQ-HX-06PH | 75 | 26 | 38 | 24 | 21 | ￠10 |
| PARTNO. | LS | ￠D | HEX1 | A | T | d |
| LSQ-HX-O2-SM | 52.4 | 30.4 | 24 | 14 | G1/2 | ￠8.3 |
| PARTNO. | LP | C | CP | A | ￠T | d |
| LSQ-HX-O2-PH | 56 | 20.5 | ￠16 | 30 | 9 | ￠5 |
| PARTNO. | LS | ￠D | HEX1 | A | T | d |
| LSQ-HX-KR-SF | 52 | 30.2 | 24 | 12 | G1/2 | ￠8.3 |
| PARTNO. | LP | C | CP | A | ￠T | d |
| LSQ-HX-KR-PH | 56 | 20.5 | ￠16 | 30 | 9 | ￠5 |
| PARTNO. | LP | ￠D | HEX1 | A | T | d |
| LSQ-HX-CO2-SF | 52 | 30.2 | 24 | 12 | G1/2 | ￠8.3 |
| PARTNO. | LS | C | CP | A | ￠T | d |
| LSQ-HX-CO2-PH | 56 | 20.5 | ￠16 | 30 | 9 | ￠5 |
